Panel

• Pixel Pitch(mm) : 0.153 x 0.153
• Active Display Area(mm) : 293.76 (H) x 165.24 (V)
• Viewing Angle(H/V) : 178/178
• Response Time(G-to-G) : 8ms(Typ.)
• Display Colors : 16.7 M (real 6bit, dither 8bit)
• Color Gamut : 45%
•  Haze : 10%

Display

• Dynamic C/R : MEGA
• H-Scanning Frequency : 30 – 81kHZ
• V-Scanning Frequency : 48 – 75HZ
• Maximum Pixel Frequency : 594MHz

Power

• Type : Adapter
• Power Supply : AC 100 – 240 V (+/- 10 %), 50/60 Hz
•  Power Consumption : Max[W/h]: 27.5, Typical[W/h]: 13.0, Rating[W/h]: 25.0, BTU(Max): 93.8, Sleep mode: 0.5

Internal Player

• Processor : Cortex A72 1.7GHz Quad-Core CPU
• On-Chip Cache Memory : L1 Instruction Cache : 48KBL1 Data Cache : 32KBL2 Cache : 2MB
• Clock Speed : 1.7GHz
• Main Memory Interface : 2.5GB LPDDR4 1.5GHz 64bit
• Graphic resolution : 1920×1080
• Graphics : Output resolution : 3840×2160 (Scale up from graphic processing result.)
• Storage (FDM) : 8GB (3.88GB Occupied by O/S, 4.12GB Available)
• I/O Ports : USB 2.0
• Operating System : Tizen 4.0 (VDLinux)
• Ukuran Layar: 13-inch Touch Screen

Antarmuka / Interface

• 1x HDMI
• 1x USB
• 1x HDCP
• RS232
• RJ45
• Stereo Mini Jack
• Built in Speaker
