Product Category

• Layer 2+

Port Specifications

• 16x Total number of RJ45 ports
• 4x Total number of optical ports
• 4x Number of 10GE SFP+ ports
• 16x Number of 10/100/1000/2500BASE-T ports

Power Supply and Consumption

• 16x Number of PoE Out ports
• 12 x Number of PoE/PoE+ Out ports
• 4 x Number of PoE/PoE+/PoE++ Out ports
• PoE budget 370 W
• PoE power pins Ports 1–4: 1–2(-), 3– 6(+), 4–5(+), 7–8(-); Ports 5–16: 1–2 (+), 3–6 (-)

System Specifications

• Forwarding rate 119.04 Mpps

Environment and Reliability

• MTBF 400,000 hours
• Operating temperature 0°C to +50°C (32°F to 122°F)
• Altitude Operating altitude: –500 m to +5,000 m (–1,640.42 ft. to +16,404.20 ft.)
  Storage altitude: –500 m to +5,000 m (–1,640.42 ft. to +16,404.20 ft.)
• Surge protection Service port: ±6 kV for common mode
  Power connector: ±6 kV for both common mode and differential mode

Basic Configurations

• PoE watchdog

Interface

• Jumbo frame length (MTU) 9216 bytes (interface configuration mode)

Security

• Port isolation

• Broadcast storm control
