Product Category

• Layer 3

Port Specifications

• 48 x RJ45 console port
• 4 x Total number of optical ports
• 4x  Number of 10GE SFP+ ports
• 48 x Number of 10/100/1000BASE-T ports

Power Supply and Consumption

• 48 x Number of PoE Out ports
• 48  x Number of PoE/PoE+ Out ports
• 8 x Number of PoE/PoE+/PoE++ Out ports
• PoE budget 740 W
• PoE power pins Ports 1–8: 1–2(-), 3– 6(+), 4–5(+), 7–8(-); Ports 9–48: 1–2 (+), 3–6 (-)

System Specifications

• Forwarding rate 132 Mpps
• Switching capacity 176 Gbps(bit/s)

Environment and Reliability

• MTBF 400,000 hours
• Operating temperature: 0°C to +50°C (32°F to 122°F)
• Operating altitude: –500 m to +5,000 m (–1,640.42 ft. to +16,404.20 ft.)
• Storage altitude: –500 m to +5,000 m (–1,640.42 ft. to +16,404.20 ft.)
• Surge protection Service port: ±6 kV for common mode
  Power connector: ±6 kV for both common mode and differential mode.

Basic Configurations

• PoE watchdog

Interface

• 9216 bytes (interface configuration mode)

Security

• Port isolation
• Broadcast storm control
